 04 Logistics Heavy Forklifts HNF 160S 15t-18t Compact Low Mast |
 04 Logistics Heavy Forklifts HNF 160S 15t-18t Compact Low Mast Technical Datas |
| Item | Description | Unit | Design Value | |||
| HNF-150 | HNF-160S | HNF-160 | HNF-180 | |||
| Feature | Rated Load | Q(t) | 15 | 16 | 16 | 18 |
| Load Center | c(mm) | 900 | 900 | 900 | 900 | |
| Wheelbase | y(mm) | 3800 | 3800 | 3800 | 3800 | |
| Weight | Weight | kgs | 24000 | 21500 | 25000 | 25500 |
| Wheel Chassis | Tire Specifications: Front | 12.00-24-18PR | 12.00-24-18PR | 12.00-24-18PR | 12.00-24-18PR Deep Pattern |
|
| Tire Specifications: Rear | 12.00-20-18PR | 12.00-20-18PR | 12.00-20-18PR | 12.00-20-18PR Deep Pattern |
||
| Wheels, Qty, Front/Rear (X-Drive Wheels) | 4/2 | 4/2 | 4/2 | 4/2 | ||
| Wheel Distance: Front | b10(mm) | 2060 | 2060 | 2060 | 2060 | |
| Wheel Distance: Rear | b11(mm) | 2330 | 2330 | 2330 | 2330 | |
| Basic Dimension | Front/Back Inclination Angle of Mast/Fork Rack |
Degree(°) | 6/12 | 6/12 | 6/12 | 6/12 |
| Height of Mast when Retracted |
h1(mm) | 3625 | 2760 | 3625 | 3675 | |
| Standard Lifting Height | h3(mm) | 3500 | 2850 | 3500 | 3500 | |
| Max. Lifting Height | h4(mm) | 5375 | 3960 | 5375 | 5375 | |
| Overhead Guard Height (Cab Height) | h6(mm) | 3365 | 2760 | 3365 | 3365 | |
| Total Length (including Fork Length) | l1(mm) | 7640 | 7500 | 7640 | 7640 | |
| Distance from Vertical Front Surface of Fork to Rear End of Vehicle |
l2(mm) | 5840 | 5700 | 5840 | 5840 | |
| Total Width | b1/b2(mm) | 2750 | 2750 | 2750 | 2750 | |
| Fork Sizes | s/e(mm) | 1800*220*100 | 1800*220*110 | 1800*220*100 | 1800*220*100 | |
| Fork Frame Width | b3(mm) | 2700 | 2700 | 2700 | 2700 | |
| Min. Ground Clearance under Mast (Full Load) | m1(mm) | 265 | 175 | 265 | 265 | |
| Min. Ground Clearance of Center of Wheelbase (Full Load) | m2(mm) | 325 | 260 | 325 | 325 | |
| Min. Turning Radius | Wa(mm) | 5800 | 5800 | 5800 | 5800 | |
| Performances | Operating Speed (Full Load/No Load) | km/h | 26/30 | 26/30 | 26/30 | 26/30 |
| Max. Lifting Speed (Full Load/No Load) | mm/s | 250/260 | 220/270 | 250/260 | 250/260 | |
| Max. Descent Speed (Full Load/No Load) | mm/s | 430/330 | 430/330 | 430/330 | 430/330 | |
| Traction | kN | 150 | 150 | 150 | 150 | |
| Gradeability (Full Load/No Load) | % | 20/22 | 20/22 | 20/21 | 20/21 | |
| Service Brake | Hydraulic Clamp Disc Type |
Hydraulic Clamp Disc Type |
Hydraulic Clamp Disc Type |
Hydraulic Clamp Disc Type |
||
| Internal Combustion Engine |
Brand/Model | Option #1 | China Weichai | China Weichai | China Weichai | China Weichai |
| YYC6J150-T301 | YYC6J150-T301 | YYC6J175-T302 | YYC6J175-T302 | |||
| Option #2 | Dongfeng Cummins | Dongfeng Cummins | Dongfeng Cummins | Dongfeng Cummins | ||
| 6BTAA5.9-C190 III | 6BTA5.9-C130 | 6BTAA5.9-C190 III | 6BTA5.9-C130 | |||
| Option #3 | Dongfeng Cummins | Dongfeng Cummins | Dongfeng Cummins | Dongfeng Cummins | ||
| QSB6.7-C190 III | QSB4.5-C130 III | QSB6.7-C190 III | QSB6.7-C190 III | |||
| Cylinder No. | 6 | 6 | 6 | 6 | ||
| Others | Transmission Gear Number (Front/Rear) | 2/1 | 3/3 | 2/1 | 2/1 | |
| Attachments Working Pressure | MPa | 16 | 16 | 16 | 16 | |
| Amount of Oil for Attachments | L/min | 60 | 60 | 60 | 60 | |
| Note: Due to technical improvements, the datas may not match the products. If there is any discrepancy, please refer to the products, that is, the above datas are subject to change without prior notice. | ||||||
